SEVA-EASYdrive-Sercos III

Sercos III interface card for EASYdrive.

The Sercos III bus system belongs to the fieldbus family. The network is usually

constructed in a linear structure. The maximum data transfer rate on a Sercos III bus

can be up to 100 Mbit/s. The fieldbus cable is connected exclusively via

the two M12 connectors on the front. Please note that the

incoming bus line to the “In” socket and the outgoing line to the “Out” socket

If it is the last participant, the “Out” socket is free

to leave – a terminating resistor is not required.

Including M12 connection cable 2 m, M12 connector / RJ45 connector / 4-pin / 2 m / D-coded.

-The interface card is part of the inverter and cannot be retrofitted.-

All product photos are non-binding examples! Technical changes reserved.
