SEVA-EASYdrive-EtherCAT

EtherCAT interface card for EASYdrive.

The EtherCAT bus system belongs to the fieldbus family. The network is usually implemented in

linear structure. The maximum data transfer rate on an EtherCAT bus can

up to 100 Mbit/s. The fieldbus cable is connected exclusively via the

two M12 connectors on the front. Please note that the

incoming bus line to the “In” socket and the outgoing line to the “Out” socket

If it is the last participant, the “Out” socket is free to

– a terminating resistor is not required.

Including M12 connection cable 2 m, M12 connector / RJ45 connector / 4-pin / 2 m / D-coded.

The interface card is part of the inverter and cannot be retrofitted.

All product photos are non-binding examples! Technical changes reserved.
