SEVA forced-air fan BG112

Fan cover with external fan for motors of size 112. 1 x 230V / 50Hz

Weight: 4.0kg

35 W, 1x230 V-50 Hz, 0.13 A
2300 rpm, IP 54
- Ø 222 mm, length 240 mm

To install the external fan, it is necessary to remove the fan cover and
to remove the fan blade. If an extension cannot be used,
the shaft must be shortened. When ordering with motor, the external fan can also be mounted
delivered. Please select the version.
