SEVA- CMRV050 IEC71 i=10 worm gear
SEVA- CMRV050 IEC71 i=10 worm gear
SEVA- CMRV050 IEC71 i=10 worm gear
SEVA- CMRV050 IEC71 i=10 worm gear
SEVA- CMRV050 IEC71 i=10 worm gear

SEVA- CMRV050 IEC71 i=10 worm gear

Key Features

  • Worm gear with IEC flange to the motor side, Ratio (i)= 10, Hollow shaft= 25mm, IEC input hollow shaft= 14 x 30mm,
  • IEC input flange B14 = 105 x 70 x 85mm, suitable for motors of frame size 71 in B14
  • IEC input flange B5 = 160 x 110 x 130mm, suitable for motors of frame size 71 in B5
  • Weight = 3.5 kg, Color = RAL 5010 (gentian blue)
  • The gearbox can be used in both directions of rotation
Downloads
Eigenschaften

Wird geladen …

Wird geladen …

IEC input flange: B14
€185,52 EUR
€185,52 EUR

* plus VAT plus shipping costs

SKU: CSG05010070

Payment Methods

  • American Express
  • Apple Pay
  • Google Pay
  • Klarna
  • Mastercard
  • PayPal
  • Visa

Accesories

Wird geladen...
Description
Description
x

Worm gear with IEC flange to the motor side,

Ratio (i)= 10, Hollow shaft= 25mm, IEC input hollow shaft= 14 x 30mm,

IEC input flange B14 = 105 x 70 x 85mm, suitable for motors of frame size 71 in B14

IEC input flange B5 = 160 x 110 x 130mm, suitable for motors of frame size 71 in B5

Weight = 3.5 kg, Color = RAL 5010 (gentian blue). The gearbox can be used in both directions of rotation

operated and includes an oil filling upon delivery.

All product photos are non-binding examples! Technical changes reserved.
