Frekvensomformer LS 008M100
Wichtigste Merkmale
- Frekvensomformer, 0.75 kW, 230V, 4.2A, IP20, EMC filter integrated, - EMC filter C2 - Potentiometer for hastighed control - Montering on montering plates or DIN rail - Side-by-side installation possible (2mm distance between the FU) - Easy connection via RJ45 port - Standard IO: 3x DI, 1x DO, 1x AI (0-10V), 1x AO (0-10V) - Bremse chopper on 1.5kW and 2.2kW versions - Overload capacity 150% for 1 min - Programming med DriveView7 drift software via RJ45 connection on the M100 (Advanced only
- The standard version does not have an RJ45 interface
- Please select a version.)
- Extract fra specific functions: - DC braking - Jog betjening - 3-wire betjening - Dwell betjening - Slip compensation - PID control - Energy-saving mode - Hastighed search - Autilmatic restart
Downloads
Eigenschaften
Wird geladen …
| Serie | M100 - the compact one |
| Leistung | 0.75 kW |
| Spannung | 1 x 230 V |
| Schutzart | IP20 |
| Lieferzeit | ca. 3-4 arbejdsdage |
- €132,28 EUR
- €132,28 EUR
- Unit price
- per
* plus VAT plus forsendelse costs
Lieferzeit
ca. 3-4 arbejdsdage
SKU:
66430004
Betalingsmetoder
Beskrivelse
xFrekvensomformer, 0.75 kW, 230V, 4.2A, IP20, EMC filter integrated,
- EMC filter C2
- Potentiometer for hastighed control
- Montering on montering plates or DIN rail
- Side-by-side installation possible (2mm distance between the FU)
- Easy connection via RJ45 port
- Standard IO: 3x DI, 1x DO, 1x AI (0-10V), 1x AO (0-10V)
- Bremse chopper on 1.5kW and 2.2kW versions
- Overload capacity 150% for 1 min
- Programming med DriveView7 drift software via RJ45 connection on the M100
(Advanced only! The standard version does not have an RJ45 interface! Please select a version.)
Extract fra specific functions:
- DC braking
- Jog betjening
- 3-wire betjening
- Dwell betjening
- Slip compensation
- PID control
- Energy-saving mode
- Hastighed search
- Autilmatic restart
